    Pneumatic Driven TSR Controller T600M Thermo King T Series

    Ask Lasest Price
    Brand Name : CH
    Model Number : T-series
    Price : USD
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 1000 Unit
    Delivery Time : 20-35 work day
    • Product Details
    • Company Profile

    Pneumatic Driven TSR Controller T600M Thermo King T Series

    Pneumatic Driven TSR Controller T600M Thermo King T Series​

    product Introductionn:

    SPECIFICATIONS T-600M T-700M T-800M T-900M T-1000M T-1100M
    REFRIGERATION CAPACITY: SYSTEM NET COOLING CAPACITY AT 30°C AMBIENT TEMPERATURE UNDER A.T.P. CONDITIONS

    Engine Power (W)

    0℃6,0006,5507,6008,0509,15010,600
    -20℃3,7004,0004,3004,5005,4505,700

    Electric Stand-by (W)

    0℃3,7004,6005,9006,2006,4006,720
    -20℃2,6003,2003,3003,4704,2004,410
    HEATING CAPACITY: BOX TEMPERATURE 2℃, AMBIENT TEMPERATURE -18℃
    Engine power(W)3,1003,1003,1003,1004,1004,100
    Engine power and Water-heating(optional)(W)6,3006,3006,3006,3007,3007,300
    AIRFLOW: ON HIGH SPEED ENGINE OPERATION
    Airflow volume @ 0 Pa static pressure (m3/h)2,7002,7002,7002,7003,2003,200
    WEIGHT: NOT INCLUDES BATTERY
    Model 30: cooling and heating on engine operation (kg)443440443440461457
    Model 50: cooling and heating on engine and stand-by operation (kg)468465468465510505
    ENGINE: LOW EMISSIONS, 3 CYLINDER, LIQUID COOLED
    ModelTK 370TK 370TK 370TK 370TK 376TK 376
    Rating (kW)11.211.211.211.214.614.6
    Maintenance interval (hr)2,0002,0002,0002,0002,0002,000
    COMPRESSOR: LIGHTWEIGHT ALUMINIUM ALLOY
    ModelX214X214X214X214X426 C5X426 C5
    Displacement (CC)228228228228426426
    ELECTRIC STAND-BY OPTION
    Voltage / Phase / Frequency (V/Ph/Hz)380V/3Ph/50Hz
    Rating (kW)4.54.54.54.57.57.5
    REFRIGERANT: R-404A ZERO OZONE DEPLETION POTENTIAL (ODP), INTERNATIONALLY APPROVED
    Charge (kg)3.63.03.93.04.13.0


    The GreenTech Engine from Thermo King Low emissions, high performance

    All the T-Series truck refrigeration units are equipped with the new range of GreenTech engines from Thermo King. These engines drastically reduce emissions, waste and noise pollution, exceeding all known requirements, including the most stringent EU standards. So, when you see the

    GreenTech name and symbol, you know at a glance that you are looking at refrigeration units that contain the cleanest engines on the market today.

    Performance has been enhanced too; GreenTech engines are more powerful and cause less stress to components. It is the easy choice for you and the best choice for the environment.

    Powerful and simple to use, the new TSR T-Series controller makes it easy for your drivers to accurately manage the temperature in the truck, no matter what you are hauling.

    Step-by-step instructions, depicted in symbolic form, make it quick and easy to precisely set and adjust the refrigeration unit, helping your drivers, your customers and ultimately your bottom line.

    T-Series Product Model:

    .T-600M

    .T-700M

    .T-800M

    .T1000M ,T-1100M


    T-Series Key Features:

    Easy to use and service

    • The new and intuitive TSR controller features a symbolic display for error-free operation

    • Low level alerts for oil and coolant

    • Programmable service intervals and scheduled maintenance reminders

    • Easy service accessibility to electrical and engine components

    • Easy to use PC Monitor application for diagnostics and communication with USB port


    WhisperTM quiet operation

    Poly-V stretch belt with Quiet Channel technology for reduced noise



    T-Series Specifications:

    T-Series Dimension(mm):
